MandiFlat Foam

MandiFlat Foam provides acoustic absorption for applications seeking a flat, smooth appearance with no pattern. MandiFlat foam is available in 60cm x 120cm sheets and in 25mm 0r 50mm thicknesses. Consisting of a lightweight, Class 1 fire-rated acoustical core, this foam may be used in a wide range of applications. MandiFlat Foam is installed with construction adhesive.

MandiFlat Foam delivers a versatile wall and ceiling panel for use in applications like offices and recording studios, as well as in tougher industrial applications. There is no itchy fiberglass to cut or clean up. Standard foam sheets are 60cm x 120cm in size and thicknesses of 2.5cm and 50cm. Choose from white and grey colors.

Please enable JavaScript in your browser to complete this form.
Name
Email Address

Applications:

  • Houses of Worship

  • Corporate offices

  • Healthcare

  • Restaurants

  • Schools and Universities

  • Teleconferencing and Videoconferencing Rooms

  • Broadcast and Recording Studios

  • Multi-Purpose Rooms

  • Home Theaters and Auditoriums

Features:

  • Reduces echo and reverberation

  • Exceptional acoustical performance

  • Mold-resistant, fire-retardant

  • Great for use as HVAC duct liner to reduce noise

Technical Information for MandiFlat Foam:

  • Size: 60cm x 120cm

  • Thickness: 25mm and 50mm

  • Material:Open-cell melamine-based foam

  • Intended Use:Interior, sound absorption

  • Color: Grey or White

  • Fire Rating: Class 1

  • NRC: : (25mm) 0.50, (50mm) 0.90

Installation Method:

  • These panels are mount to any wall or ceiling surface with water-based construction adhesive

  • Melamine foam is fragile, please handle with care.

  • Maintain uniform temperature of prior to, during and after installation.

SOUND ABSORPTION (HZ)

1/3 Octave Band Center Frequencies In Hz.)

Thickness 125Hz 250Hz 500Hz 1KHz 2KHz 4KHz Overall NRC
25mm
0.18
0.08
0.41
0.69
0.84
0.8
0.50
50mm 0.19 0.56 0.91 1.01 1.03 1.03 0.95

FOR MORE INFORMATION ON OUR MANDIFLAT FOAM CALL US ON 078 562 5428 or Contact our sales team
